simple Kenwei vacuum packaging machine design
1.Screw type feeding mechanism with strong convenient capacity and wide application range.
2.The feeding tray can be equipped with a five-blade upper feeding hopper mechanism to asjust the feeding direction according to the material distribution of the main vibrator pan.
3.Equipped with anti-hanging dimple discharge device to prevent material hanging on the machine.
4.The concepts of waterproof,dustproof,and insulate dust are integrated into each part of the machine,which is easy to clean and wash.
5.The touch screen man-machine interface is used to facilitate selflearning and information exchange with others.
| Model | JW-A14 |
| Identify Code | A14-2-12 |
| Weighing Range | 100-500g |
| Accuracy*1 | X(0.5) |
| Max Speed*2 | 40P/M |
| Hopper Volume | 2.5L |
| Control Panel | 10.1"Touch Screen |
| Options | Timing Hopper/Printer/Reject Device |
| Driving System | Step Motor |
| Power Requirement | 200V/1800W/50/60Hz/8A |
| Packing Dimension(mm) | 1120(L)X1282(W)X2398(H) |
| Gross Weight | 400kg |
| *1: Can refer to the national standard GB/T27738-2011 or the international Legal Organization No.61 International Recommendation OIML R61 2004(E) | |
| *2: Depends on product shape, product density, target weight, etc. | |
It is suitable for automatic weighing of all kinds of soft and slender sticky materials with water, such as various noodles, rice flour, rice noodles, kelp, wakame, etc.
