Kenwei 2 Head Linear Weigher 1.6/2.0Lmanufacturing

Product details of the 2 head linear weigher

Product Specification

Availability: OEM/ODM

Product Introduction

The design of Kenwei 2 head linear weigher varies with the market trend. The product is examined as per industry standards to make sure it is free from flaws. The product is highly durable and has strong practicality.

The standard combined scale uses high-speed spring-free hopper, a new spring-free aluminum shell design structure, weighing more stable and fast. Integrative welding of mouthpiece case and middle seat greatly enhances the strength of the machine. It is suitable for weighing granular materials such as melon seeds, peanuts, nuts, almonds, raisins, candies and pistachios. The 14 head combined scale has 1.6L and 2L hopper selection. The maximum weighing speed can reach 120 packs/minute, and the weighing speed is fast.

• 01
  Special load cell with high precision and high standard
• 02
  Intelligent fault alarm, convenient maintenance
• 03
  High speed staggered discharging function, effectively prevent blocking materials

• 04
  With high integrated modular design makes mechanical and electronic components easy to install and    maintenance
• 05
  Modbus industry-standard communication protocol, realize the interface combination of multihead weigher and packaging machine
• 06
  Other features are the same as first-generation models

1.High speed hoppers without springs to avoid the broken spring falling into packages

2. New springless actuator design makes weighing more stable and fast

3. Machine case and middle seat integral welding greatly enhance the strength of the machine, makes    the hopper shorter stable time

Technical Specification

bg

Model	JW-A10	JW-A14
Identify Code	A10-3-2	A14-3-2
Weighing Range	10-1000g	10-1500g
Accuracy	X(0.5)	X(0.5)
Max Speed	65P/M	120P/M
Hopper Volume	1.6/2.0L
Control Panel	10.1'' Touch Screen
Options	Dimple Plate/Timing Hopper/Printer/Reject Device
Driving System	Step Motor
Power Requirement	220V/1000W/ 50/60Hz/10A	220V/1500W/ 50/60Hz /10A
Packing Dimension(mm)	1620(L)*1080(W)*1110(H)	1760(L)*1190(W)*1390(H)
Gross Weight	400kg	500kg

Applications

bg

 It’s suitable for weighing seeds, peanuts, nuts, almonds, raisins, candy, pistachio, potato chips, dumplings, and other granules, sheet, strip, round shape material.

Company Advantage

• Having developed rapidly for years, Kenwei is a machinery manufacturer with a relatively large scale and great business capability.
• Kenwei's products are exported to many countries and regions around the world.
• Kenwei's location enjoys traffic convenience with multiple traffic lines passing through. This is conducive to the outward transportation and is the guarantee of timely supply of products.
• We have the powerful team management, strong production team, customer-focused business team, and inexorable research and development team to offer favorable conditions for our development.
• Based on the loyal customer service consciousness, our company shows a good image to the customers and provides the best service for them.
Want to get a durable high-tech multihead weigher,weight checker,packaging machine,linear weigher,food metal detector,counting machine,packing accessories? Please contact Kenwei.
