online industrial scale manufacturers easy to disassemble for factories
1. The material for Kenwei checkweigher for sale is carefully selected. Such properties and behaviors as strength, hardness, durability, flexibility, weight, resistance to heat and corrosion, electrical conductivity, and machinability are required.
2. The implementation of the quality management system ensures the product meets the international standards.
3. Guangdong Kenwei Intellectualized Machinery Co.,LTD. fully understand the customer's sensitive points and pain points.
4. To ensure quality, Guangdong Kenwei Intellectualized Machinery Co.,LTD. conducts strict quality management system.
The check weigher is used to check whether the weight of a single product is in accordance with the set goal, and the sorting device automatically eliminates the substandard products. It has the eliminating methods of rocker arm, pneumatic push rod, blowing, sliding, etc. The maximum conveying speed of the sorting scale is 55 meters per minute, and it can handle many different packaging styles, including bulk paper bags, plastic bags, cartons, metallized film packaging, etc.
product features
Technical Specification
Model | JW-C200 | JW-C1000 | JW-C2000 |
Identify Code | C200-1-1 | C1000-1-1 | C2000-1-1 |
Weighing Range | 5-200g | 100-1000g | 10-2000g |
Accuracy | XIII(1) | XIII(1) | XIII(1) |
Max.Belt Speed | 55m/min | 52m/min | 52m/min |
Max.Speed | 100 PCS | 80/PCS | 80PCS |
Belt width | 150mm | 220mm | 300mm |
Belt Size | 350(L)*160(W)mm | 450(L)*220(W)mm | 450(L)*300(W)mm |
Power Requirements | 220V/ 500W / 50/60Hz | 220V/500W / 50/60Hz | 220V/500W / 50/60Hz |
Packing Dimension(mm) | 1250(L)*570(W)*1150(H) | 980(L)*800(W)*1290(H) | 980(L)*860(W)*1290(H) |
Reject Method | Air blowing | Air blowing/Air-reject/Pneumatic pusher/Slide type | |
Model | JW-C3000 | JW-C6000 |
Identify Code | C3000-1-1 | C6000-1-1 |
Weighing Range | 10-3000g | 10-6000g |
Accuracy | XIII(1) | XIII(1) |
Max.Belt Speed | 40m/min | 40m/min |
Max.Speed | 70PCS | 70 PCS |
Belt width | 400mm | 400mm |
Belt Size | 650(L)*400(W)mm | 650(L)*400(W)mm |
Power Requirements | 220V/700W/ 50/60Hz | 220V/700W/50/60Hz |
Packing Dimension(mm) | 1400(L)×950(W)×1530(H) | 1400(L)X950(W)X1530(H) |
Reject Method | Air blowing/Air-reject/Pneumatic pusher/Slide type | |
Applications
It is used to check whether the single bag weight is conformed to the preset weight or not and auto remove the unqualified products by the rejection device .
Company Features
1. Guangdong Kenwei Intellectualized Machinery Co.,LTD. is powerful enough to offer the most considerate service and the best industrial scale .
2. We have personnel that is experts in product creation. They are accustomed to multi-disciplinary approaches in manufacture. Being fast, professional, competent, and knowledgeable, they allow us to provide the best.
3. We are committed to playing a key role in achieving a sustainable future. We promote responsible and ethical business practices, actively support the activities of the communities in which we live and work and foster environmentally sound operations. Guangdong Kenwei Intellectualized Machinery Co.,LTD. constantly improves our designs to win the world market.
