Kenwei weight checker from China
1. The tests for Kenwei check weigher are strictly conducted. It has been tested in terms of mechanical components safety, the whole machine safety, operation safety, and environmental safety. Quality control from material to finished product is taken strictly over Kenwei packaging machine
2. There is technical support available for weight checker. Kenwei packaging machine is of high accuracy, which helps customers save materials
3. The product works stably under harsh conditions. Its mechanical parts, treated under different corrosive medium, can operate stably in acid-base and mechanical oil environment. Component replacement of each Kenwei packaging machine is simple and without trouble
4. This product can be used for a long time during operation. It can withstand corrosion, corrosion, fatigue, creep and thermal shock throughout the life of the product. Kenwei packaging machine is manufactured based on industry standards
5. The product has the advantage of high precision. It is specially processed under the lathes which are designed for cutting the metal in the most precise way. Kenwei packaging machine is easy to clean
The check weigher is used to check whether the weight of a single product is in accordance with the set goal, and the sorting device automatically eliminates the substandard products. It has the eliminating methods of rocker arm, pneumatic push rod, blowing, sliding, etc. The maximum conveying speed of the sorting scale is 55 meters per minute, and it can handle many different packaging styles, including bulk paper bags, plastic bags, cartons, metallized film packaging, etc.
product features
Technical Specification
Model | JW-C200 | JW-C1000 | JW-C2000 |
Identify Code | C200-1-1 | C1000-1-1 | C2000-1-1 |
Weighing Range | 5-200g | 100-1000g | 10-2000g |
Accuracy | XIII(1) | XIII(1) | XIII(1) |
Max.Belt Speed | 55m/min | 52m/min | 52m/min |
Max.Speed | 100 PCS | 80/PCS | 80PCS |
Belt width | 150mm | 220mm | 300mm |
Belt Size | 350(L)*160(W)mm | 450(L)*220(W)mm | 450(L)*300(W)mm |
Power Requirements | 220V/ 500W / 50/60Hz | 220V/500W / 50/60Hz | 220V/500W / 50/60Hz |
Packing Dimension(mm) | 1250(L)*570(W)*1150(H) | 980(L)*800(W)*1290(H) | 980(L)*860(W)*1290(H) |
Reject Method | Air blowing | Air blowing/Air-reject/Pneumatic pusher/Slide type | |
Model | JW-C3000 | JW-C6000 |
Identify Code | C3000-1-1 | C6000-1-1 |
Weighing Range | 10-3000g | 10-6000g |
Accuracy | XIII(1) | XIII(1) |
Max.Belt Speed | 40m/min | 40m/min |
Max.Speed | 70PCS | 70 PCS |
Belt width | 400mm | 400mm |
Belt Size | 650(L)*400(W)mm | 650(L)*400(W)mm |
Power Requirements | 220V/700W/ 50/60Hz | 220V/700W/50/60Hz |
Packing Dimension(mm) | 1400(L)×950(W)×1530(H) | 1400(L)X950(W)X1530(H) |
Reject Method | Air blowing/Air-reject/Pneumatic pusher/Slide type | |
Applications
It is used to check whether the single bag weight is conformed to the preset weight or not and auto remove the unqualified products by the rejection device .
Company Features
1. Guangdong Kenwei Intellectualized Machinery Co.,LTD. is a large-scale backbone enterprise specializing in the production of weight checker.
2. We have excellent manufacturing and innovation capabilities guaranteed by international advanced weight check machine equipment.
3. In order to create a healthy and sustainable living condition for the next generations, our company is trying best to protect the environment. We handle all the scrap, waste gases, and wastewater strictly in line with relevant regulations. Inquire online!
