Kenwei low moq packaging machine factory
1. 1.6L larger open door, suitable for weighing larger materials, a wide range of applications. Mold-making processes and uniform design standards contribute to better interchangeability for parts.
2. Air pressure system built-in cabinet prevents the electronic components from being damaged due to humidity.
3. The double support of the infeed funnel is easier to adjust and more convenient to clean. An integral machine frame with middle standing enhances the strength of the machine, making the time for stabilizing hoppers much shorter.
4.100 degrees chute, the inner side of the case is an independent transmission line, so that the material and the belt contact are more elastic, to achieve the effect of breakage-proof.
| Model | JW-A14 |
| Identify Code | A14-2-14 |
| Weighing Range | 10-1500g |
| Accuracy*1 | X(0.5) |
| Max Speed*2 | 70P/M |
| Hopper Volume | 1.6L |
| Control Panel | 7"Touch Screen |
| Options | Dimple Plate/Timing Hopper/Printer/Reject Device |
| Driving System | Step Motor |
| Power Requirement | 220V/1000W/50/60Hz/10A |
| Packing Dimension(mm) | 1930(L)X1460(W)X1040(H)/1820(L)X1100(W)X290(H) |
| Gross Weight | 530kg |
*1: Can refer to the national standard GB/T27738-2011 or the international Legal Organization No.61 International Recommendation OIML R61 2004(E) | |
| *2: Depends on product shape, product density, target weight, etc. | |
It is suitable for the breakage-proof quantitative weighing of materials with low free fall combination,such as Yuntun,dumplings,egg rolls,etc.
