cheap filling machine from China
Three layers screw feeding weigher is linear case arrangement, three-layer hopper structure layout, effectively reducing occupied area, using screw feeding mode, instead of traditional vibration feeding mode, suitable for viscous materials, such as mustard pickle, pickle, small fish and other materials with poor fluidity.In order to effectively solve the sticking phenomenon of Super Viscous materials, the springless scraper hopper is adopted, which makes the cleaning more convenient and fast.
Product Features
1.Special load cell with high precision and high standard;
2.Module electric board,and with intelligent multiple sampling stable mode, make weighing higher accurate;
3.Intelligent fault alarm, convenient maintenance;
4.High speed staggered discharging function, effectively prevent blocking materials;
Product Characteristic
2. The upper hopper has a stirring device, which effectively solves the sticky material feeding problem.;
4. Belt collection makes the material collect easier, faster and more efficient;
Technical Specification
Model | JW-A8 |
Identify Code | A8-4-2 |
Weighing Range | 10-200g |
Accuracy | X(0.5) |
Max Speed | 60P/M |
Hopper Volume | 1.5L |
Control Panel | 10.1” Touch Screen |
Options | Timing Hopper/Printer/Reject Device |
Driving System | Step Motor |
Power Requirement | 220V/1000W/ 50/60Hz /10A |
Packing Dimension(mm) | 2100(L)x900(W)x1290(H) |
Gross Weight | 350kg |
Applications
It’s suitable for weighing mustard, pickles, small fish and other irregular sticky materials with poor flowability.
